Explore The New MRX Series

New features, capabilities and robust integration position Anthem MRX Series as the ultimate power center of premium home theater and audio.

Introducing anthem Web User Interface

Anthem Web User Interface is now built in to all MRX Receivers and AVM Processors. Using a phone, tablet or laptop, owners can easily access any function or setting and make changes on the fly. Power the main or second zone on and off, adjust volume, change audio modes or tweak channel trims for a perfect surround sound experience. Web UI can also be used to calibrate speaker delays and levels and configure network settings/control options. Source devices can be renamed, simplifying set up by enabling the elimination of unused inputs. Installers can import and export files to make remote management simple and convenient.

Channel Re-Assignment

MRX Series Receiver channels can be assigned in many ways. Unused amplifier channels can be re-assigned to Bi-Amplify demanding front speakers, power surrounds, presence speakers, or a second zone (Available on MRX 1140 and MRX 740).

Configure amplifier channels for your system's needs, then perfect the presentation with ARC Genesis.

Robust Integration

The Anthem MRX 540 features external control and IP control capabilities for easy customization and compatibility with third-party integration solutions.

Design

At Anthem, we have one simple goal – to design, engineer and manufacture audio/video products that deliver premium performance and convenience at a reasonable price. We do this by spending thousands of hours selecting and testing components, carefully designing our own circuit topologies, and backing them with robust power supplies that ensure maximum long-term quality and reliability. We achieve this with our team at the Paradigm/Anthem Research Center and their decades of combined experience.

NEW! ARC Genesis Software

ARC Genesis is the newest software that works with many ARC enabled Anthem or Paradigm product. New features include support for both Mac and Windows; new target curve adjustment options including deep bass and high frequencies; improved algorithms and much more.

ARC Genesis is backwards compatible with many Anthem and Paradigm products that are ARC or PBK enabled. For a complete list, please visit AnthemARC.com. This third generation of Anthem Room Correction software represents a significant leap forward in room correction with the most comprehensive set of features yet. ARC Genesis transforms the audio performance of compatible speakers or electronics while retaining the unique character of any room. Proprietary Digital Signal Processing (DSP) software works in tandem with a calibrated microphone (provided with many ARC and PBK enabled products) to provide astonishing improvements to the sound you hear.

ARC Genesis works with Mac or PC and is the most comprehensive method of transforming the sound in your room. Includes many new features. Download the FREE software at AnthemARC.com.

The Anthem Advantage

Backed by over 35 years of home-grown,hands-on design, and innovative audio engineering experience, Anthem products provide an unprecedented level of reliability and functionality; delivering one of the industry’s highest performance/price ratios. This is just one reason why Anthem electronics are the choice of knowledgeable audiophiles, professional musicians and engineers the world over.

Specifications

Maximum Output (<0.1% THD)

• 5.2 VRMS, 7.1 VRMS

Frequency Response

• 20Hz - 30KHz +/-0.2dB

THD+N (2 Vrms output)

• -100 dB

S/N Ratio (2 Vrms output, IEC-A filter)

• 110 dB

PREAMPLIFIER + AMPLIFIER (1 W OUTPUT)

MRX 1140 / MRX 740

• SNR: 91 dB ch 1-5, 86 dB others

MRX 540

• SNR: 91 dB ch 1-5

SPEAKER IMPEDANCE

• Compatible with 4 Ohms or higher impedance.

MAXIMUM CONTINUOUS OUTPUT (1% THD)

Channels 1-5, Two Driven into 8 Ohms

• MRX 1140: 140 W
• MRX 740: 140 W
• MRX 540: 100 W

Channels 1-5, Two Driven into 6 Ohms

• MRX 1140: 170 W
• MRX 740: 170 W
• MRX 540: 130 W

Remaining Channels, Two Driven into 8 Ohms

• MRX 1140: 60 W
• MRX 740: 60 W
• MRX 540: N/A

Remaining Channels, Two Driven into 6 Ohms

• MRX 1140: 75 W
• MRX 740: 75 W
• MRX 540: N/A

POWER CONSUMPTION

Typical Load

• MRX 1140: 570 W
• MRX 740: 485 W
• MRX 540: 365 W

Standby

• 0.3 W

Standby IP Control Enabled

• 1.8 W

Standby HDMI Bypass Enabled

• 4.9 W

DIMENSIONS

Height (without feet)

• 6" (15.24 cm)

Height with Rackmount Kit

• 4U

Width

• 17" (43.18 cm)

Depth (including wifi ant not power cord)

• 14.5" (36.4 cm)

WEIGHT

MRX 1140

• 33.6 lb (15.2 Kg)

MRX 740

• 33.2 lb (15.1 Kg)

MRX 540

• 28.2 lb (12.8 Kg)

POWER REQUIREMENT

120 V Version

• In countries where the line voltage is 120 V, this product operates from a single phase AC power source that supplies between 108 V and 132 V at a frequency of 60 Hz.

220-240 V Version

• In countries where the line voltage is 220, 230, or 240 V, this product operates from a single phase AC power source that supplies between 198 V and 264 V at a frequency of 50 Hz.
