Feel the power of every frame with the MRX Series and its advanced 8K HDMI 2.1 Platform with HDCP 2.3. Showcasing 7 dedicated 8K inputs which support 8K/60Hz or 4K/120Hz pass-through and 3 dedicated outputs with Enhanced Audio Return Channel, you can enjoy 8K quality video from all of your 8K source devices in amazing clarity. Also featuring the latest HDMI technology and specification, the MRX 540, 740 and 1140 allow you to take your home entertainment to the next level with HDR10+, Dynamic HDR10+, ALLM and VRR support. The possibilities are limitless; unlock the true potential of your media with the industry’s most flexible and feature-rich HDMI platform.

It’s never been a more exciting time to be a gamer. With the latest consoles offering up to 4K/120Hz graphics, realistic HDR and Dolby Vision dynamic range, and immersive Dolby Atmos sound, you have to make sure your Home Theater gear won’t hold you back. Enter the MRX Series, our most feature-rich AV receivers to date!

Channel Re-Assignment

The built in high performance amplifier modules can be configured in many ways to suit the specific speaker configuration. Unused amplifier channels can be re-assigned to Bi-Amplify demanding front speakers, power surrounds, presence speakers, or a second zone (Available on MRX 1140 and MRX 740).

Configure amplifier channels for your system's needs, then fully optimise the presentation with ARC Genesis.

Robust Integration

Our latest Anthem MRX series features external control and IP control capabilities for easy customization and compatibility with third-party integration solutions.

Design

At Anthem, we have one simple goal – to design, engineer and manufacture audio/video products that deliver premium performance and convenience at a reasonable price. We do this by spending thousands of hours selecting and testing components, carefully designing our own circuit topologies, and backing them with robust power supplies that ensure maximum long-term quality and reliability. We achieve this with our team at the Paradigm/Anthem Research Center and their decades of combined experience.

Anthem
Remote App

Gain unprecedented command over your network-enabled Anthem A/V Receiver, Processor or Pre-amplifier.

The Anthem Remote App uses a Wifi connection to simplify the configuration of supported Anthem devices. App-based controls include volume level, muting, input selection, power, listening modes, bass, treble, level trims, menu navigation, and Anthem Room Correction (ARC) control.

ARC Genesis is the newest software that works with many ARC enabled Anthem or Paradigm product. New features include support for both Mac and Windows; new target curve adjustment options including deep bass and high frequencies; improved algorithms and much more.

ARC Genesis is backwards compatible with many Anthem and Paradigm products that are ARC or PBK enabled. For a complete list, please visit AnthemARC.com. This third generation of Anthem Room Correction software represents a significant leap forward in room correction with the most comprehensive set of features yet. ARC Genesis transforms the audio performance of compatible speakers or electronics while retaining the unique character of any room. Proprietary Digital Signal Processing (DSP) software works in tandem with a calibrated microphone (provided with many ARC and PBK enabled products) to provide astonishing improvements to the sound you hear.

The Anthem Advantage

Backed by over 35 years of home-grown,hands-on design, and innovative audio engineering experience, Anthem products provide an unprecedented level of reliability and functionality; delivering one of the industry’s highest performance/price ratios. This is just one reason why Anthem electronics are the choice of knowledgeable audiophiles, professional musicians and engineers the world over.

Specifications

Maximum Output (<0.1% THD)

• 5.2 VRMS, 7.1 VRMS

Frequency Response

• 20Hz - 30KHz +/-0.2dB
• Analog-Direct: N/A

THD+N (2 Vrms output)

• -100 dB

S/N Ratio (2 Vrms output, IEC-A filter)

• 110 dB

PREAMPLIFIER + AMPLIFIER (1 W OUTPUT)

MRX 1140 / MRX 740

• SNR: 91 dB ch 1-5, 86 dB others

MRX 540

• SNR: 91 dB ch 1-5

SPEAKER IMPEDANCE

• Compatible with 4 Ohms or higher impedance.

MAXIMUM CONTINUOUS OUTPUT (1% THD)

Channels 1-5, Two Driven into 8 Ohms

• MRX 1140: 140 W
• MRX 740: 140 W
• MRX 540: 100 W

Channels 1-5, Two Driven into 6 Ohms

• MRX 1140: 170 W
• MRX 740: 170 W
• MRX 540: 130 W

Remaining Channels, Two Driven into 8 Ohms

• MRX 1140: 60 W
• MRX 740: 60 W
• MRX 540: N/A

Remaining Channels, Two Driven into 6 Ohms

• MRX 1140: 75 W
• MRX 740: 75 W
• MRX 540: N/A

POWER CONSUMPTION

Typical Load

• MRX 1140: 570 W
• MRX 740: 485 W
• MRX 540: 365 W

Standby

• 0.3 W

Standby IP Control Enabled

• 1.8 W

Standby HDMI Bypass Enabled

• 4.9 W

DIMENSIONS

Height (without feet)

• 6" (15.24 cm)

Height with Rackmount Kit

• 4U

Width

• 17" (43.18 cm)

Depth (including wifi ant not power cord)

• 14.5" (36.4 cm)

WEIGHT

MRX 1140

• 33.6 lb (15.2 kg)

MRX 740

• 33.2 lb (15.1 kg)

MRX 540

• 28.2 lb (12.8 kg)

POWER REQUIREMENT

120 V Version

• In countries where the line voltage is 120 V, this product operates from a single-phase AC power source that supplies between 108 V and 132 V at a frequency of 60 Hz.

220-240 V Version

• In countries where the line voltage is 220, 230, or 240 V, this product operates from a single-phase AC power source that supplies between 198 V and 264 V at a frequency of 50 Hz.
