KEY FEATURES

• 4K UHD Pixel shift (3840 x 2400)
• 24/7 operation
• Laser Light Source
• Wifi Option
• HDBaseT - Video, and control over lan connection
• 8 Lens Options
• Warp and Blending

WUXGA – Beyond Full HD Resolution With WUXGA resolution (1,920 x 1,200 pixels)

you enjoy a sharp, clear display of Full HD video (1,920 x 1,080 pixels) images down to the smallest details even on large-screen projections for an incredibly dynamic viewing experience
Well-balanced Whites

The laser light source produces a nicely balanced RGB color for brilliant white highlights that bring a refreshing vibrancy to your images.

High-definition Images with 4K Lens and Enhancement Technology

4K enhancement technology shifts each pixel diagonally by 0.5 pixels to double the resolution to 3840 x 2160, surpassing Full HD image quality to give you unbelievable sharpness, clarity, and detail on all your presentations. By reengineering the internal structure, color bleeding is kept to an absolute minimum to deliver 4K resolution throughout the entire zoom range

High Contrast Ratio

Enjoy richer contrast with Epson’s newly-developed laser optical engine system. And combined together with the vibrant and realistic colors from the 3LCD panels, you enjoy more lifelike projections. Laser technology dims the light source in real-time according to the input video signal to deliver absolute black during full-black screens

Frame Interpolation

Enjoy clearer, sharper playback even on fast-moving subjects with Epson’s Frame Interpolation Technology. This unique function effectively eliminates motion blurring by inserting intermediate frames between images to create a smoother motion transition.

Super Resolution with Detail Enhancement

Improve perceived image resolution with the super-resolution technology. And with Epson’s detail enhancement, you enjoy rich textures for further enhancement in image quality, allowing you to select your preferred image characteristics for different scenes and content.

Advanced Colour Adjustment

With the color adjustment function, you can easily adjust the hue, saturation, and brightness for each component of RGB CMY to match your preferences.

Fine-tuning Brightness

The EB-L30000U provides precise brightness adjustment in increments of 1%. This combined with the Constant Brightness mode maintains brightness at a given value to match the venue or subject to deliver astonishing picture quality.

Auto Colour Adjustment

The built-in camera detects screens that have become unevenly colored over time, allowing the projector to automatically correct color. It also detects subtle color inconsistencies between multiple projectors. This function can be programmed to check color manually or automatically at regular intervals to deliver stable image quality with minimum maintenance.

Revolutionary Laser Light Source

Blue light from the laser is projected through a beam splitter, which divides the light into two beams. One beam passes through a phosphor wheel, turning it yellow, while the other beam remains blue. The two beams are then recombined into white light and separated into red, green, and blue through dichroic mirrors. Each of the three colors passes through LCD panels, producing three individual images, which are transmitted through a prism and combined into thenal full-color image.

Inorganic LCD Panels and Phosphor Wheel for Outstanding Reliability

Made of inorganic material, Epson’s newly developed phosphor wheel offers superior light and heat resistance to deliver excellent reliability. By combining this with our inorganic LCD panels, we create laser projectors that project bright, vibrant images for extremely long periods.

20,000 Hours of Maintenance-free Use

Engineered with inorganic LCD panels and an inorganic phosphor wheel, this newly designed laser light source delivers 20,000 hours* of maintenance-free use. And with the advanced electrostatic? later having an equally long-lasting life, you enjoy peace of mind in using this highly reliable laser projector.

Fully Sealed Optical Engine

Key optical components including the inorganic panel, inorganic phosphor wheel, and laser bank are housed in a sealed structure to prevent external dust contamination. Does this mean brightness deterioration due to dust is significantly reduced so you can use your projector with confidence even in a smoky environment?

Powered Lens with Stepping Motor

The powered lens with a stepping motor offers limitless possibilities in projector placement. Covering a wide range of angles, the motorized lens shift gives you a great deal of flexibility when installing the projector. The newly adopted stepping motor lets you make highly precise adjustments when employing edge blending, stacking, and other techniques. Adjustments can also be made via remote control or over a network, enhancing usability even for ceiling-mounted projectors.

Lens Position Memory

With storage for up to 10 settings in the projector memory, including shift positions, focus and projection sizes, you can easily and quickly adjust the projector according to the aspect ratio of content simply by using either the remote controller or command control.

Wider Lens Shift Range

The extremely wide-ranging lens shift was realized through a change in design and careful consideration of the lens and optical engine. Coupled with an improved stepping motor, the range shift mechanism allows more precise adjustment for limitless possibilities in projector placement

Multi-directional Projection

The EB-L30000U can be rotated 360° in any direction — horizontally, vertically and rotationally — without any loss in image brightness, making it ideal for a wide range of applications, including projecting onto ceilings and floor

Projection on Wide Curved and Corner Spaces

Fit your projection images nicely even on non-? at surfaces. Create stunning projection images on wide curved surfaces and corner walls, ideal for advertisements and marketing promotions.

Specifications

Projection System:

• Technology: 3LCD Technology, RGB liquid crystal shutter
• LCD Panel: 1.03 inch with C2 Fine

Image:

• Color Light Output: 30,000 Lumen (Normal), 20,000 Lumen (Eco)
• White Light Output: 30,000 Lumen (Normal), 20,000 Lumen (Eco)
• Resolution: WUXGA (1920 x 1200)
• Resolution Enhancement: 4K Enhancement
• Aspect Ratio: 16:10
• Contrast Ratio: Over 5,000,000:1
• Native Contrast: 2,000:1
• Colour Reproduction: Up to 1.07 billion colors
• HDR Support: HDR10, HLG

Optical:

• Light Source: Laser
• Laser Light Source Life:
  • 20,000 hours (Normal Mode)
  • 30,000 hours (Eco Mode)
• Throw Ratio: 0.35 - 10.11:1
• Zoom: Motorized, Factor: 1 - 2.9x
• Lens Shift: Motorized - Vertical ± 60 %, Horizontal ± 30 %
• Lens Position Memory: 10 positions
• Screen Size: 50 inches - 600 inches
• Projection Distance Wide/Tele: Varies by lens
• Projection Lens F Number: Varies by lens
• Projection Lens Focal Length: Varies by lens
• Projection Lens Focus: Motorized
• Interchangeable Lens: Yes
• Standard Lens: Not included

Connectivity:

• Interfaces:
  • USB 2.0-A (2x)
  • USB 2.0 Type B (Service Only)
  • RS-232C
  • Ethernet Interface (1000 Base-T/ 100-Base TX/ 10-Base-T)
  • VGA in
  • DVI in
  • HDMI (HDCP 2.3) (2x)
  • HDBaseT
  • 3G-SDI Input (2x)
  • 3G-SDI Output
  • Jack plug out
  • Wireless LAN IEEE 802.11a/b/g/n (optional)
  • Near Field Communication (NFC)
  • USB content playback
  • Remote

Advanced Features:

• Security: Kensington lock, Security bar, Password lock, Wireless LAN unit lock, Wireless LAN security, Password protection
• Other Features:
  • 21:9 aspect ratio support
  • A/V mute
  • Auto Power On
  • Auto source search
  • Direct Power on/off
  • Edge Blending
  • Freeze image
  • Horizontal and vertical keystone correction
  • Lens position memory
  • Long light source life
  • OSD copy function
  • Point correction
  • Power on button
  • Quick Corner
  • Schedule Function
  • Split-Screen Function
  • Super resolution
  • Web Control
  • Web Remote
  • iProjection App

Video Color Modes:

• Cinema
• Dynamic
• Natural
• Presentation
• DICOM SIM
• Multi Projection
• BT709

Projector Control:

• Via: AMX, Crestron, Extron

General:

• Power Consumption:
  • Normal Mode: 1,300 Watt
  • Eco Mode: 1,050 Watt
  • Standby Mode: 0.5 Watt
• Heat Dissipation: 4,431 BTU/hour (max)
• Supply Voltage: AC 200 V - 240 V, 50 Hz - 60 Hz
• Product Dimensions: 652 mm x 532 mm x 300 mm (WxDxH)
• Product Weight: 37 kg
• Noise Level:
  • Normal Mode: 40 dB (A)
  • Economy Mode: 35 dB (A)
• Supported Temperature:
  • Operation: 5° C - 35° C
  • Storage: -10° C - 60° C
• Supported Humidity:
  • Operation: 20% - 80%
  • Storage: 10% - 90%
• Included Software:
  • Epson Creative Projection
  • Epson Projector Config Tool
  • Epson Projector Content Manager
  • Epson Projector Management
  • Epson Projector Professional Tool
• Options:
  • Camera module
  • Ceiling mount
  • Wireless LAN unit
• Room Type / Application:
  • Large Venue
  • Auditorium
  • Conference Room
  • Rental and Staging
  • Projection Mapping
• Positioning: Ceiling Mounted, Desktop, Flying Frame
