MUSIC STREAMING THROUGHOUT YOUR HOME
With HEOS® Built-in, easily access streaming music and share with HEOS-enabled speakers in other rooms.
MUSIC STREAMING THROUGHOUT YOUR HOME
With HEOS® Built-in, easily access streaming music and share with HEOS-enabled speakers in other rooms.
HDMI Connectivity with ARC/eARC
Supports the latest HDMI technology on inputs and output. ARC (Audio Return Channel) or eARC (Enhanced Audio Return Channel) makes playing TV audio through your receiver simple, with just a single HDMI connection.
8K/HDCP 2.3
Enjoy pristine 8K picture quality on your 8K TV or projector. Supports both 8K pass-through and 8K upscaling of 4K content. Supports HDCP 2.3, the latest copy protection standard, for peace of mind when streaming copy-protected content.
Brilliant colour from HDR 10+
Supports HDR (High Dynamic Range), HLG (Hybrid Log Gamma), as well as Dynamic HDR and HDR10+ pass-through. HLG offers HDR technology over broadcast content. Both Dynamic HDR and HDR10+ use dynamic metadata to optimize shadows and highlights as screens change.
Dolby Vison
Dolby Vision is a stunning HDR imaging technology that brings extraordinary colour, contrast, and brightness to the screen. Compatible with Dolby Vision so you can enjoy Dolby Vision content from a compatible source device and TV.
Number of Power Amps
2
Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive)
100 W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)
120W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive)
175 W
Output power 8 Ohm (20 Hz - 20 kHz, T.H.D. 0.07%)
100 W (0.08%)
Total Harmonic Distortion
0.0001
Input Sensitivity: MM
2.5 mV / 47 kohm
Signal to Noise Ratio: MM/MC
74 dB / -
Input Sensitivity: High level
200mV / 47k ohm
Signal to Noise Ratio: High level
98dB
Treble Control
± 6 dB at 20kHz
Bass Control
± 6 dB at 20Hz
Channels
2
Digital in: USB-B / optical / coaxial / USB-A
- / 2 / 1 / 1
Sample Rate digital In
192 kHz / 24-bit
USB-A: DSD / WAV / FLAC / AIFF / ALAC
<=5.6 / 192 / 192 / - / 192
DAC chip
PCM1690
Tuner: DAB / DAB+ / FM (RDS)
o / o
Bluetooth / aptX / NFC
o / - / -
Streaming audio from PC
o
Wi-Fi / Wired LAN
o / o
Internet radio
o
AirPlay 2
o
Roon Tested
o
Spotify Connect* / Tidal* / Deezer* / others *
o / o / o / o
Amazon Prime Music* / Pandora*
o / -
HEOS Multiroom and Streaming
o
Voice Control - Works with Amazon Alexa
o
DSD-Audio network streaming
o
Lossy Formats: MP3 / WMA / AAC
o / o / o
Lossless Formats: DSD / FLAC HD 192/24 / ALAC 96/24 / WAV 192/24 / AIFF
o / o / o / o / -
Gapless Playback
o
Remote APP: iDevice / Android
o / o
Power amp discrete construction
o
Balance / Bass / Treble / Loudness
o / o / o /
