The Michi X5 Series 2 Integrated Amplifier is authoritative and precise, capable of delivering a speaker-taming 600 watts of Class AB output power. The X5’s linear power supply is built around two massive in-house manufactured, shielded, low-noise toroidal transformers. Equipped with an ESS SABRE 8-Channel Digital to Analog converter, this amplifier renders ultra-revealing music with breath taking accuracy.
A wide array of inputs ensures support of your favourite music sources including Analog RCA and XLR Balanced, Moving Magnet or Moving Coil Phono, aptX™ HD Wireless Bluetooth, Coaxial and Optical. The PC-input supports PCM (32-bit 384kHz) and Quad DSD (11.2MHz) with full MQA hardware decoding up to 24-bit 384kHz.
Whether you're a music lover, audiophile, professional sound engineer or all of the above, the Michi X5 Series 2 Integrated Amplifier has been passionately engineered for you. Meticulously manufactured to the highest standards of build quality, and featuring an understated, graceful industrial design, the Michi X5 Series 2 is sure to quickly become the centrepiece of your audio system.
Michi, expectations amplified.
Specifications:
Dimensions (W × H × D)
485 x 195 x 452mm
19" × 7 5/8" × 17 3/4"
Front Panel Height
177 mm (7")
Power Requirements
230V, 50Hz
Power Consumption
850W
Standby Power Consumption
<0.5W
Net Weight
43.8kg (96.56 lbs.)
BTU Rating
2194 BTU/h
Continuous Power Output
600W/Ch (4Ω)
350W/Ch (8Ω)
Total Harmonic Distortion (THD)
<0.009%
Frequency Response
Line Level Inputs: 10Hz - 100kHz (+0 dB, -0.6 dB)
Digital Inputs: 20Hz - 20kHz (0 ± 0.4 dB)
Phono Input: 20Hz - 20kHz (+0 dB, -0.2 dB)
S/N Ratio (IHF "A" Weighted)
Line Level Inputs: 102dB
Digital Inputs: 102dB
Phono Input: 80dB
More Specifications
Intermodulation Distortion (60Hz:7kHz, 4:1)
<0.03%
Damping Factor (20 Hz - 20kHz, 8 ohms)
350
Input Sensitivity
Line Level Inputs (RCA): 380mV
Line Level Inputs (XLR): 580mV
Phono Input (MM): 5.7mV
Phono Input (MC): 570 uV
Input Impedance
Line Level Inputs (RCA): 100kΩ
Line Level Inputs (XLR): 100kΩ
Digital Inputs: 75Ω
Phono Input (MM): 47kΩ
Phono Input (MC): 100Ω
Input Overload
Line Level Inputs (RCA): 12.5V
Line Level Inputs (XLR): 12.5V
Phono Input (MM): 197mV
Phono Input (MC): 19mV
Preout Level
1V
Tone Controls
±10dB at 100Hz / 10kHz
Coax/Optical Digital Input Signals
SPDIF LPCM (Up to 24-bit/192kHz)
PC-USB
USB Audio Class 1 (up to 24-bit/96kHz)
USB Audio Class 2 (up to 32-bit/384kHz)
DSD and DoP support
MQA and MQA Studio support
Roon Tested
